Insulated Hinged Door with Emerson Pump for Custom Cold Storage Marine Coolroom Walk-in Freezer Cold Rooms

Product Description

Professional Cold Room Solutions

Providing comprehensive cold room projects and products for domestic and overseas customers across the world. With thousands of completed cold room projects and commercial refrigerators, our expertise spans across more than 40 countries.

Cold Storage Overview

Versatile Applications

  • Hospitality & Food Service: Hotels, Restaurants, and Catering.
  • Healthcare: Hospitals, Blood Banks, and Medical Processing.
  • Agriculture: Poultry Slaughter, Aquaculture, and Mushroom Cultivation.
  • Production: Beverage Production, Beer Cooling, and Chemical Product Cooling.
  • Logistics: Large-scale Cold Storage and Logistics Centers.
Cold Room Application

Core Components & Specifications

PU and PIR Insulated Sandwich Panels

Our cold rooms are constructed with high-quality Polyurethane (PU) or PIR sandwich panels, offering superior heat insulation and structural intensity to minimize heat transmission waste.

PU Panel Structure PIR Panel Feature
Specification Details
MaterialPolyurethane foam with Color Steel, Stainless Steel, or Aluminum Sheet
Thickness50mm / 100mm / 150mm / 200mm
Fire Proof GradeB1 - B2 Grade
Density40-42 kg/m³
Waterproof Rate< 4%
FeaturesCam lock system, Embossed style available

XPS Flooring (Extruded Panel)

Excellent heat preservation using 50mm thickness, 2-3 layer XPS extruded boards. Features include compressive strength ≥ 350 kPa and B1/B2 flame retardant properties.

XPS Panel

Cold Room Doors & Refrigeration Units

  • Doors: Manual and Automatic styles (Swing, Sliding, and CA doors).
  • Compressors: Utilizing world-class brands like Bitzer, Copeland, Tecumseh, and Frascold.
Cold Room Doors Refrigeration Unit

Global Project Showcase

Food Chain Cold Storage (Uzbekistan)

Scales: 5000 M² / Height 6m. Completed in 40 days.

Uzbekistan Project
Installation Process 1 Installation Process 2

Regional Cold Storage (Cambodia & Singapore)

Customized designs focusing on safety, efficiency, and energy conservation based on local climate conditions.

Cambodia Project Singapore Project

International Food Chain (Canada)

Features chiller and freezer rooms (-5℃/-18℃) meeting Europe and CE standards.

Canada Project

Our Services & Expertise

As a professional group providing one-stop refrigeration solutions, we specialize in OEM/ODM services for commercial refrigerators, kitchen refrigeration, chest freezers, and beverage coolers. All products are certified with CE, ROHS, SASO, NSF, and ISO 9001.

Production Facility Related Products

Frequently Asked Questions

Q1: What information is needed for a cold room inquiry? Please provide the usage (e.g., vegetables, fish, medical), required temperature, cold room dimensions (Length*Width*Height), and your local power supply (Voltage/Phase/Hertz).
Q2: What is the standard thickness of PU panels for different temperatures? We offer 50mm, 100mm, 150mm, and 200mm thicknesses. Generally, 100mm is used for chillers and 150mm-200mm for deep freezers to ensure optimal insulation.
Q3: Which compressor brands do you use in your systems? We utilize high-end international brands including Bitzer (Germany), Copeland (USA), Tecumseh, and Frascold (Italy) to ensure reliability and efficiency.
Q4: Are your panels fire-resistant? Yes, our PU and PIR panels are available in B1 and B2 fire-retardant grades, meeting international safety standards.
Q5: Do you provide customized sizes for cold rooms? Absolutely. We provide one-stop solutions and can customize the dimensions, door styles, and refrigeration capacity to fit your specific storage needs and space.
Q6: What certifications do your refrigeration products carry? Our products are certified with CE, ROHS, SASO, NSF, and ISO 9001, ensuring high quality and compliance for global markets.
