📦Product Description
Four port frequency RFID reader/writer module is adopted to fully support EPC C1G2 ISO18000 - 6B/C, GB/T29768-2013 (optional) and other mainstream UHF RFID medium interface protocols. The working frequency band supports national standard dual band 920MHz ~ 925MHz, 840MHz to 845MHz, FCC 902MHz to 928MHz, and ETSI 865MHz ~ 868MHz. Output power is 0dBm ~ 33dBm optional, featuring long identification distance, fast speed, multi-label recognition ability, and strong anti-interference performance. It is designed for high protection and ease of installation.
🚀Key Features
Support tags conforming to standards EPC global UHF ISO-18000-6C (EPC G2), TK900.
Frequency range 902~928MHz (or customized).
Support multi communication interfaces: LAN, RS232, RS485, Wiegand 26/34.
4 SMA antenna ports, 7dbi circular polarization antenna with adjustable height.
RF output power 20 ~ 30dBm adjustable; supports auto, command, and trigger work modes.
Reliable industrial structure design, suitable for varied severe environments.
🛠️Product Application
Vehicle Management: Monitoring and managing autos and containers.
Customs Management: Greatly speeds up the customs process.
Logistics Management: Efficient parcels and warehouse management.
Access Control: Including car access and personal access control.
Production Line: Monitoring products from end to end.
Asset Management: Dramatically improved security levels.
Frequently Asked Questions
What RFID protocols does this reader support?
It fully supports EPC global UHF ISO-18000-6C (EPC G2) and TK900 standards, ensuring compatibility with most mainstream UHF RFID tags.
What is the frequency range of the gantry reader?
The standard range is 902~928MHz, but it can be customized to 865~868MHz or other regional standards as required.
Which communication interfaces are available for integration?
The device supports multiple interfaces including LAN (Ethernet), RS232, RS485, and Wiegand 26/34, making it easy to integrate with various management systems.
Does the system support secondary development?
Yes, we provide a full SDK (Software Development Kit) and a DEMO application to support automated reading and writing tag integration.
What is the core technology used in this reader?
The reader is powered by the high-performance Impinj R2000 chip, which provides superior sensitivity and anti-interference capabilities for multi-tag environments.
Is the antenna height adjustable for different vehicles?
Yes, the gantry structure features 4 SMA antenna ports and the height of the antennas is adjustable to accommodate different vehicle sizes and container heights.
