Integrated Parking Access Control & Barrier Gate Solution

Customization:	Available
Warranty:	at Least 1 Year
Position:	Central Isolation Barrier

Send Inquiry

Product Description

📋 Basic Specification

Model NO.

IDL

Material

Steel

Post Fixation

Polymer Base

Name

Vehicle Safety Barrier

Color

Orange/Grey, Other Colors Selectable

Voltage

AC220/AC110 50/60Hz

Rated Power

100W

Temperature

-30°C < C < 80°C

Cabinet Weight

55kg

Arm Speed

1.2s, 3s, 5s (Suggest 3s)

Pole Length

Max 6 Meters (Suggest 3m)

Capacity

10000 Set / Month

Trademark

IDL

Origin

China

HS Code

847190

🚀 High Quality Automatic Barrier Gate

Standard barrier gate featuring up to 6m arm length. Arm Speed options include 1.2s, 3s, and 5s (3s recommended). Suitable for both outdoor and indoor environments.

This digital barrier gate is designed for modern management requirements, emphasizing "safety, quickness, high efficiency, and high quality." It is ideal for parking lots, hotels, schools, garden villas, enterprises, and public institutions.

⭐ Main Features

High system integration and powerful functionality.

Elevating overtime and motor overheating protection to prevent abnormal damage.

Hall sensing device for inductive limit control, ensuring non-contact work and no abrasion.

Imported large power relay with original packaging for reliable operation.

Photoelectric isolated protection circuit to ensure signal integrity and interference resistance.

Wireless remote control with high-performance learning codes for stability.

Unique arc extinction processing circuit to extend control panel service life.

Transformer with imported magnetic core for stable work in moist outdoor environments.

Extra 12V/100mA power supply for connecting limit detection devices.

⚙️ Technical Parameters

Voltage	AC220/AC110 50/60HZ
Rated Power	100W
Motor Working Temp	-30°C < C < 80°C
Cabinet Weight	55KG
Protection Grade	IP44
Arm Speed	1.2s, 3s, 5s (Suggest 3s)
Pole Length	Up to 6m (Suggest 3m)
Rod Center Height	830mm or 890mm
Remote Distance	> 30 Meters
Communication	RS232 (Direct PC connection)
Input Interface	+12V level signal or pulse (>100MS)

🖼️ Product Display

❓ Frequently Asked Questions

1. What is the maximum arm length for this barrier gate?

The barrier gate can support a pole length of up to 6 meters, though we suggest using a 3-meter arm for optimal performance.

2. How fast does the barrier arm operate?

There are three speed options available: 1.2 seconds, 3 seconds, and 5 seconds. We generally recommend the 3-second setting for standard use.

3. Can the barrier gate withstand extreme weather conditions?

Yes, the motor is designed to operate in temperatures ranging from -30°C to 80°C, and the cabinet features an IP44 protection grade for outdoor durability.

4. What type of remote control system does it use?

It utilizes a high-performance wireless remote control receiving module with a range of more than 30 meters, integrating one million groups of learning codes.

5. Is it possible to connect the barrier gate to a computer?

Yes, the gate includes an enhancement type RS232 communication interface which allows it to be connected directly to a computer for management.

6. What safety protections are built into the system?

The system includes motor overheating protection, elevating overtime protection, and Hall sensing for non-contact inductive limit control to prevent mechanical wear.
